Breaking torque wrench 5AR-N Norbar 500-1500NM 3/4

BREAKING TORQUE WRENCH 5AR-N NORBAR 3/4 500-1500NM

Product benefits

  • Easy to read scale is shielded from dust, dirt and spray
  • Unique profiled cam and reaction plate - gives much clearer ' torque break point' reducing the possibility of over torqueing
  • Robust construction gives accurate results to ±4% even in arduous working conditions
  • Easy to set accurately
  • Can be split and packed in two parts for a smaller, easier to transport package
  • Push-through ratchet allows two direction torqueing
  • Designed to be cost effectively serviced
  • New handle - more comfortable and guides operator's hand to correct position
  • Supplied with a Declaration of Conformance, which meets the requirements of ISO 6789-1:2017

Description

Industrial series breaking torque wrench with scale and ratchet head. New generation of the highly valued breaking torque wrench. Designed to be more compact and robust with continued ease of use. Ideal for heavy industrial applications. Can be divided into two parts and transported in the practical plastic box provided. Push-through ratchet head allows torque tightening to both left and right. Clear scale for torque setting. The breaking torque wrench signals with a clicking sound when the correct torque is reached and breaks off, minimizing the risk of overtightening the torque.

Attributes

ETIM class codeEC002132
Manufacturer´s description120118
Inaccuracy+/- 4 %
Length1232 mm
Torque range, max1500 Nm
Torque range, min500 Nm
Thread directionRight, Left
Measurement unitsNm
Torque directionLeft
Torque typeSignalling, Indicating
Tap typeSquare
Width303 mm
Height151 mm
Weight12.75 kg

Article information

Base unitPCS
Contents (Per base unit)1 PCS á 1 ST
Minimum order quantity1 PCS
CurrencySEK
GTIN/EAN5060207566728
