267230605
Cross line laser Leica Lino P5-1
CROSS LASER LINO P5-1Description
Cross dot laser Lino P5-1. Robust cross dot laser that shows both dots with a red laser light. One dot points down, up, right, left and straight forward. The dots make it easy to scale a height and to plumb a point from floor to ceiling. Operates with alkaline batteries or a rechargeable Li-ion battery pack. Supplied with laser, target, magnetic mount Twist 360, alkaline battery holder and 3 pcs AA batteries, all packaged in a hard case. Suitable stand 9677-1100 or 16006-0109.
Attributes
| ETIM class code | EC000641 |
| Manufacturer´s description | LINO P5-1 |
| Inaccuracy, horizontal, points | ± 0,2mm/m |
| Inaccuracy, line | ± 0,3mm/m |
| Inaccuracy, vertical, points | ± 0,3mm/m |
| Work range with receiver | 30 m |
| Threaded mount | 1/4 tum |
| Enclosure class IP | IP54 |
| Laser type | Cross line laser, Dot laser |
| Levelling range | ± 4 ° |
| No. of batteries | 3 pcs |
| Battery | Li-ion 2 |
| Battery type | Alkaline |
| Battery type IEC | LR06 |
| Width | 60 mm |
| Depth | 100 mm |
| Height | 110 mm |
| Weight | 495 g |
Article information
| Base unit | PCS |
|---|---|
| Contents (Per base unit) | 1 PCS á 1 ST |
| Minimum order quantity | 1 PCS |
| Currency | SEK |
| GTIN/EAN | 7640110697566 |
- Articles
- Specifications
- Compare Articles
- Accessories
- Similar Products
GTIN
| Item no. | Description | Pack | Contents |
|---|---|---|---|
| 267230605 | CROSS LASER LINO P5-1 | ||
| GTIN: 7640110697566 | PCS | 1 | |
