301200101
Reciprocating compressor ABAC Baseline B20
COMPRESSOR ABAC BASE 2 24 V2Description
Baseline B20 direct driven reciprocating compressors. Suitable for semi-pros or DIY enthusiasts, suitable for basic maintenance work or joinery, such as blow cleaning, pumping tyres, nailing, spot blasting, simple paint jobs, etc. Also for the occasional use of drills and small impact wrenches. Simple, flexible handling.
Attributes
| ETIM class code | EC002860 |
| Manufacturer´s description | Pole Position B20 Baseline |
| Working pressure, max. | 8 Bar |
| Frequency | 50 Hz |
| Throughput cylinder volume | 190 l/min |
| Length | 558 mm |
| Sound power level (LW) | 85 dB(A) |
| Sound pressure level (Lp) | 65 dB(A) |
| Rated current | 7 A |
| Motor output (hp) | 2 hp |
| Motor output (W) | 1.5 kW |
| Motor voltage | 230 V |
| Speed compressor block | 2850 RPM |
| Volume, air tank | 24 l |
| No. of bevels | 1-phase |
| Cylinder type | Piston |
| Drive type | Direct drive |
| Enclosure class IP | IP20 |
| Oil lubrication | Yes |
| Flexible | Portable |
| Width | 332 mm |
| Height | 579 mm |
| Weight | 25 kg |
Article information
| Base unit | PCS |
|---|---|
| Contents (Per base unit) | 1 PCS á 1 ST |
| Minimum order quantity | 1 PCS |
| GTIN/EAN | 8020119147979 |
- Articles
- Specifications
- Compare Articles
- Documents
- Similar Products
GTIN
| Item no. | Description | Pack | Contents |
|---|---|---|---|
| 301200101 | COMPRESSOR ABAC BASE 2 24 V2 | ||
| GTIN: 8020119147979 | PCS | 1 | |
| 301200200 | COMPRESSOR ABAC BASE 2 50 V2 | ||
| GTIN: 8020119147986 | PCS | 1 | |
